Intel Arc A770 vs Radeon Pro 5300M

Limited
Intel Arc A770 Buy Now ↗
VS
Discontinued
Radeon Pro 5300M Buy Now ↗
Share this comparison: Copied!

Review

Intel Arc A770
Radeon Pro 5300M
Gaming
35
14
Workstation
43
17
AI/ML
31
6
Energy Efficiency
41
64
Quick Comparison Final Score
37
22
❖

Key differences

Key distinctions and advantages between Intel Arc A770 and Radeon Pro 5300M

Reasons to consider the Intel Arc A770

  • + Generation 12.7 architecture
  • + DG2-512 codename
  • + 16GB GDDR6 memory
  • + PCIe 4.0 x16 interface

Reasons to consider the Radeon Pro 5300M

  • + RDNA 1.0 architecture
  • + Navi 14 codename
  • + 4GB GDDR6 memory
  • + PCIe 4.0 x8 interface

Pros & Cons

Intel Arc A770
  • Large 16GB memory pool
  • Hardware ray tracing support
  • Dedicated AI tensor cores
  • Limited gaming performance at higher resolutions
  • No DLSS upscaling support

"A entry-level Intel Arc A770 graphics card with modest workstation performance (43/100). Suited for casual gaming and basic graphics tasks."

Radeon Pro 5300M
  • Dedicated AI tensor cores
  • Limited gaming performance at higher resolutions
  • No hardware ray tracing
  • No DLSS upscaling support
  • Older generation architecture

"A budget AMD Radeon Pro 5300M graphics card with limited performance overall. Suited for casual gaming and basic graphics tasks."

Gaming Performance

Forza Horizon 5

1080p High
77
Intel Arc A770 Radeon Pro 5300M

The Witcher 3

1080p High
124
Intel Arc A770 Radeon Pro 5300M

Counter-Strike 2

1080p High
118
Intel Arc A770 Radeon Pro 5300M

Far Cry 6

1080p High
97
Intel Arc A770 Radeon Pro 5300M

Hogwarts Legacy

1080p High
59
Intel Arc A770 Radeon Pro 5300M

Call of Duty

1080p High
79
Intel Arc A770 Radeon Pro 5300M

Ghost of Tsushima

1080p High
57
Intel Arc A770 Radeon Pro 5300M

Cyberpunk 2077

1080p High
80
Intel Arc A770 Radeon Pro 5300M

Tomb Raider

1080p High
106
Intel Arc A770 Radeon Pro 5300M
FPS Table
Intel Arc A770 Radeon Pro 5300M
1080p High1080p Ultra1440p Ultra4K Ultra 1080p High1080p Ultra1440p Ultra4K Ultra
Forza Horizon 5 77 — — — — — — —
The Witcher 3 124 — — — — — — —
Counter-Strike 2 118 — — — — — — —
Far Cry 6 97 — — — — — — —
Hogwarts Legacy 59 — — — — — — —
Call of Duty 79 — — — — — — —
Ghost of Tsushima 57 — — — — — — —
Cyberpunk 2077 80 — — — — — — —
Tomb Raider 106 — — — — — — —
Average FPS 89——— ————
Average FPS by Resolution
Intel Arc A770 Radeon Pro 5300M
1080p High 106 —
1080p Ultra 89 —
1440p Ultra 65 —
4K Ultra 37 —
Margin of Error Low —

Benchmarks

3D Mark
Steel Nomad Lite Score
Intel Arc A770
12648
Radeon Pro 5300M
—
Intel Arc A770 Radeon Pro 5300M
Time Spy 13554 3404
Solar Bay 51114 —
Port Royal 7231 —
Fire Strike 34163 —
Wild Life Extreme 26266 —
Night Raid 122588 —
Passmark Graphics
G3D Mark Score
Intel Arc A770 +130%
13358
Radeon Pro 5300M
5812
Intel Arc A770 Radeon Pro 5300M
G2D Mark 761 559
DirectX 11 78 FPS 36 FPS
DirectX 12 75 FPS 25 FPS
GPU Compute 5850 Ops/s 2580 Ops/s
Blender
Blender GPU
Intel Arc A770 +747%
2016.55
Radeon Pro 5300M
238.18

Specifications

GeekBench 6 OpenCL
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
GB6 Compute Score 113935 27065
Background Blur 175 img/sec 59.6 img/sec
Face Detection 98 img/sec 34.3 img/sec
Horizon Detection 3.63 Gpixels/sec 1.19 Gpixels/sec
Edge Detection 5.51 Gpixels/sec 1.56 Gpixels/sec
Gaussian Blur 8.51 Gpixels/sec 1.31 Gpixels/sec
Feature Matching 0.89 Gpixels/sec 0.28 Gpixels/sec
Stereo Matching 492.6 Gpixels/sec 95.4 Gpixels/sec
Particle Physics 24819.2 FPS 2473.3 FPS
API OpenCL OpenCL
GeekBench 6 ML
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
GB6 ML Single Precision 13344 3321
GB6 ML Half Precision 14119 3307
GB6 ML Quantized 10082 1043
Image Classification (SP) 5750 2457
Image Segmentation (HP) 16175 394
Image Super Resolution (Q) 12997 6055
Face Detection (HP) 21409 9021
Pose Estimation (Q) 67820 2239
Text Classification (SP) 849 344
Machine Translation (HP) 2627 458
Object Detection (SP) 7465 2523
Depth Estimation (Q) 24186 10775
Style Transfer (SP) 183238 30282
Framework ONNX Core ML
Backend DirectML GPU
General
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
Vendor Intel Amd
Build Discrete Discrete
Released 12-Oct-22 13-Nov-19
Case Desktop Laptop
Purpose Gaming Gaming
Segment Mid-range Mid-range
Architecture Generation 12.7 RDNA 1.0
GPU Codename DG2-512 Navi 14
Recommended CPU -Intel Core i5 12500or above
Graphics Processing Unit
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
Base Clock 2100 MHz 1000 MHz
Boost Clock 2400 MHz 1250 MHz
Shading Units 4096 1280
Texture Mapping Units (TMUs) 256 80
Render Output Units (ROPs) 128 32
Compute Units (Pipelines) 20
Tensor Cores 512 No
Ray-tracing Cores 32 No
L1 Cache
L2 Cache 16MB shared 2MB shared
Instructions Per Cycle 2 IPC 2 IPC
Raw Performance
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
Pixel Fill Rate 307 GPixel/s 40 GPixel/s
Texture Fill Rate 614 GTexel/s 100 GTexel/s
FLOPS (FP32) 19.7 TFLOPS 3.2 TFLOPS
Physical
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
Interface PCIe 4.0 x16 PCIe 4.0 x8
TGP 225 W 85 W
Manufacturing TSMC TSMC
Fabrication Process 6 nm 7 nm
Die Size 406 mm² 158 mm²
Transistor Count 21 billion 6.4 billion
Transistor Density 51.72 MTr/mm² 40.51 MTr/mm²
Max. Temperature
Memory
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
Memory Type GDDR6 GDDR6
API
Specification Intel Arc A770 ↗ Radeon Pro 5300M ↗
DirectX 12 12
Vulkan 1.3 1.2
OpenGL 4.6 4.6
OpenCL 3 2.1
CUDA
Ray Tracing Yes No
DLSS No No
DisplayPort 1.4
