Intel Arc A770 vs Intel UHD Graphics Gen 11 (24 EU)

Limited
Intel Arc A770 Buy Now ↗
VS
Limited
Intel UHD Graphics Gen 11 (24 EU) Buy Now ↗
Share this comparison: Copied!

Review

Intel Arc A770
Intel UHD Graphics Gen 11 (24 EU)
Gaming
35
3
Workstation
43
12
AI/ML
31
1
Energy Efficiency
41
80
Quick Comparison Final Score
37
18
❖

Key differences

Key distinctions and advantages between Intel Arc A770 and Intel UHD Graphics Gen 11 (24 EU)

Reasons to consider the Intel Arc A770

  • + Generation 12.7 architecture
  • + DG2-512 codename
  • + 16GB GDDR6 memory
  • + PCIe 4.0 x16 interface

Reasons to consider the Intel UHD Graphics Gen 11 (24 EU)

  • + Generation 11.0 architecture
  • + Jasper Lake GT1 codename
  • + System Shared memory
  • + Ring Bus interface

Pros & Cons

Intel Arc A770
  • Large 16GB memory pool
  • Hardware ray tracing support
  • Dedicated AI tensor cores
  • Limited gaming performance at higher resolutions
  • No DLSS upscaling support

"A entry-level Intel Arc A770 graphics card with modest workstation performance (43/100). Suited for casual gaming and basic graphics tasks."

Intel UHD Graphics Gen 11 (24 EU)
  • Great energy efficiency
  • Dedicated AI tensor cores
  • No discrete card needed — integrated solution
  • Limited gaming performance at higher resolutions
  • No hardware ray tracing
  • Older generation architecture

"A budget Intel UHD Graphics Gen 11 (24 EU) integrated graphics with limited performance overall, excellent energy efficiency. Suited for casual gaming and basic graphics tasks."

Gaming Performance

Forza Horizon 5

1080p High
77
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

The Witcher 3

1080p High
124
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Counter-Strike 2

1080p High
118
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Far Cry 6

1080p High
97
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Hogwarts Legacy

1080p High
59
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Call of Duty

1080p High
79
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Ghost of Tsushima

1080p High
57
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Cyberpunk 2077

1080p High
80
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)

Tomb Raider

1080p High
106
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)
FPS Table
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)
1080p High1080p Ultra1440p Ultra4K Ultra 1080p High1080p Ultra1440p Ultra4K Ultra
Forza Horizon 5 77 — — — — — — —
The Witcher 3 124 — — — — — — —
Counter-Strike 2 118 — — — — — — —
Far Cry 6 97 — — — — — — —
Hogwarts Legacy 59 — — — — — — —
Call of Duty 79 — — — — — — —
Ghost of Tsushima 57 — — — — — — —
Cyberpunk 2077 80 — — — — — — —
Tomb Raider 106 — — — — — — —
Average FPS 89——— ————
Average FPS by Resolution
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)
1080p High 106 —
1080p Ultra 89 —
1440p Ultra 65 —
4K Ultra 37 —
Margin of Error Low —

Benchmarks

3D Mark
Steel Nomad Lite Score
Intel Arc A770 +4919%
12648
Intel UHD Graphics Gen 11 (24 EU)
252
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)
Time Spy 13554 298
Solar Bay 51114 —
Port Royal 7231 —
Fire Strike 34163 1060
Wild Life Extreme 26266 729
Night Raid 122588 4543
Passmark Graphics
G3D Mark Score
Intel Arc A770
13358
Intel UHD Graphics Gen 11 (24 EU)
—
Intel Arc A770 Intel UHD Graphics Gen 11 (24 EU)
G2D Mark 761 —
DirectX 11 78 FPS —
DirectX 12 75 FPS —
GPU Compute 5850 Ops/s —
Blender
Blender GPU
Intel Arc A770
2016.55
Intel UHD Graphics Gen 11 (24 EU)
—

Specifications

GeekBench 6 OpenCL
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
GB6 Compute Score 113935 2769
Background Blur 175 img/sec 5.76 img/sec
Face Detection 98 img/sec 3.54 img/sec
Horizon Detection 3.63 Gpixels/sec 0.12 Gpixels/sec
Edge Detection 5.51 Gpixels/sec 0.16 Gpixels/sec
Gaussian Blur 8.51 Gpixels/sec 0.09 Gpixels/sec
Feature Matching 0.89 Gpixels/sec 0.03 Gpixels/sec
Stereo Matching 492.6 Gpixels/sec 8.23 Gpixels/sec
Particle Physics 24819.2 FPS 404.6 FPS
API OpenCL OpenCL
GeekBench 6 ML
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
GB6 ML Single Precision 13344 582
GB6 ML Half Precision 14119 684
GB6 ML Quantized 10082 449
Image Classification (SP) 5750 278
Image Segmentation (HP) 16175 400
Image Super Resolution (Q) 12997 427
Face Detection (HP) 21409 669
Pose Estimation (Q) 67820 1140
Text Classification (SP) 849 241
Machine Translation (HP) 2627 284
Object Detection (SP) 7465 319
Depth Estimation (Q) 24186 907
Style Transfer (SP) 183238 4096
Framework ONNX ONNX
Backend DirectML DirectML
General
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
Vendor Intel Intel
Build Discrete Integrated
Released 12-Oct-22 11-Jan-21
Case Desktop Laptop
Purpose Gaming Generic
Segment Mid-range Entry-level
Architecture Generation 12.7 Generation 11.0
GPU Codename DG2-512 Jasper Lake GT1
Recommended CPU -Intel Core i5 12500or above #NAME?
Graphics Processing Unit
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
Base Clock 2100 MHz 350-450 MHz (configurable)
Boost Clock 2400 MHz 750-1200 MHz (configurable)
Shading Units 4096 192
Texture Mapping Units (TMUs) 256 12
Render Output Units (ROPs) 128 6
Compute Units (Pipelines) 24
Tensor Cores 512 No
Ray-tracing Cores 32 No
L1 Cache
L2 Cache 16MB shared
Instructions Per Cycle 2 IPC 2 IPC
Raw Performance
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
Pixel Fill Rate 307 GPixel/s 5-7 GPixel/s
Texture Fill Rate 614 GTexel/s 9-14 GTexel/s
FLOPS (FP32) 19.7 TFLOPS 0.3-0.5 TFLOPS
Physical
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
Interface PCIe 4.0 x16 Ring Bus
TGP 225 W 6-10 W (configurable)
Manufacturing TSMC Intel
Fabrication Process 6 nm 10 nm
Die Size 406 mm²
Transistor Count 21 billion
Transistor Density 51.72 MTr/mm²
Max. Temperature
Memory
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
Memory Type GDDR6 System Shared
API
Specification Intel Arc A770 ↗ Intel UHD Graphics Gen 11 (24 EU) ↗
DirectX 12 12
Vulkan 1.3 1.2
OpenGL 4.6 4.6
OpenCL 3 3
CUDA
Ray Tracing Yes No
DLSS No No
DisplayPort
