Intel Xe3 Graphics vs Intel Arc A750

Available
Intel Xe3 Graphics Buy Now ↗
VS
Available
Intel Arc A750 Buy Now ↗
Share this comparison: Copied!

Review

Intel Xe3 Graphics
Intel Arc A750
Gaming
29
31
Workstation
18
38
AI/ML
12
27
Energy Efficiency
100
43
Quick Comparison Final Score
36
33
❖

Key differences

Key distinctions and advantages between Intel Xe3 Graphics and Intel Arc A750

Reasons to consider the Intel Xe3 Graphics

  • + Celestial architecture
  • + Panther Lake codename
  • + System Shared memory
  • + PCIe 5.0 interface

Reasons to consider the Intel Arc A750

  • + Generation 12.7 architecture
  • + DG2-512 codename
  • + 8GB GDDR6 memory
  • + PCIe 4.0 x16 interface

Pros & Cons

Intel Xe3 Graphics
  • Great energy efficiency
  • Hardware ray tracing support
  • No discrete card needed — integrated solution
  • Limited gaming performance at higher resolutions

"A budget Intel Xe3 Graphics integrated graphics with limited performance overall, excellent energy efficiency. Suited for casual gaming and basic graphics tasks."

Intel Arc A750
  • Hardware ray tracing support
  • Dedicated AI tensor cores
  • Limited gaming performance at higher resolutions
  • No DLSS upscaling support

"A entry-level Intel Arc A750 graphics card with modest workstation performance (38/100). Suited for casual gaming and basic graphics tasks."

Gaming Performance

Forza Horizon 5

1080p High
68
Intel Xe3 Graphics Intel Arc A750

The Witcher 3

1080p High
114
Intel Xe3 Graphics Intel Arc A750

Counter-Strike 2

1080p High
108
Intel Xe3 Graphics Intel Arc A750

Far Cry 6

1080p High
87
Intel Xe3 Graphics Intel Arc A750

Hogwarts Legacy

1080p High
50
Intel Xe3 Graphics Intel Arc A750

Call of Duty

1080p High
69
Intel Xe3 Graphics Intel Arc A750

Ghost of Tsushima

1080p High
51
Intel Xe3 Graphics Intel Arc A750

Cyberpunk 2077

1080p High
69
Intel Xe3 Graphics Intel Arc A750

Tomb Raider

1080p High
98
Intel Xe3 Graphics Intel Arc A750
FPS Table
Intel Xe3 Graphics Intel Arc A750
1080p High1080p Ultra1440p Ultra4K Ultra 1080p High1080p Ultra1440p Ultra4K Ultra
Forza Horizon 5 — — — — 68 — — —
The Witcher 3 — — — — 114 — — —
Counter-Strike 2 — — — — 108 — — —
Far Cry 6 — — — — 87 — — —
Hogwarts Legacy — — — — 50 — — —
Call of Duty — — — — 69 — — —
Ghost of Tsushima — — — — 51 — — —
Cyberpunk 2077 — — — — 69 — — —
Tomb Raider — — — — 98 — — —
Average FPS ———— 79———
Average FPS by Resolution
Intel Xe3 Graphics Intel Arc A750
1080p High — 98
1080p Ultra — 79
1440p Ultra — 59
4K Ultra — 33
Margin of Error — Low

Benchmarks

3D Mark
Steel Nomad Lite Score
Intel Xe3 Graphics
—
Intel Arc A750
10846
Intel Xe3 Graphics Intel Arc A750
Time Spy — 12425
Solar Bay — 45771
Port Royal — 6594
Fire Strike — 30444
Wild Life Extreme — 23682
Night Raid — 110785
Passmark Graphics
G3D Mark Score
Intel Xe3 Graphics
—
Intel Arc A750
12620
Intel Xe3 Graphics Intel Arc A750
G2D Mark — 737
DirectX 11 — 73 FPS
DirectX 12 — 70 FPS
GPU Compute — 5307 Ops/s
Blender
Blender GPU
Intel Xe3 Graphics
—
Intel Arc A750
2033.41

Specifications

GeekBench 6 OpenCL
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
GB6 Compute Score 23211 99280
Background Blur 57.6 img/sec 145.2 img/sec
Face Detection 29.1 img/sec 82 img/sec
Horizon Detection 0.79 Gpixels/sec 3.35 Gpixels/sec
Edge Detection 1.02 Gpixels/sec 5.01 Gpixels/sec
Gaussian Blur 1.02 Gpixels/sec 7.59 Gpixels/sec
Feature Matching 0.34 Gpixels/sec 0.81 Gpixels/sec
Stereo Matching 61.2 Gpixels/sec 462.4 Gpixels/sec
Particle Physics 3352.7 FPS 18623.1 FPS
API OpenCL OpenCL
GeekBench 6 ML
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
GB6 ML Single Precision 6638 12178
GB6 ML Half Precision 12952 12796
GB6 ML Quantized 4473 9086
Image Classification (SP) 4265 5475
Image Segmentation (HP) 11549 13781
Image Super Resolution (Q) 4466 11612
Face Detection (HP) 16012 18556
Pose Estimation (Q) 8425 58801
Text Classification (SP) 1380 824
Machine Translation (HP) 4037 2397
Object Detection (SP) 4026 6895
Depth Estimation (Q) 10708 22219
Style Transfer (SP) 35823 161148
Framework ONNX ONNX
Backend DirectML DirectML
General
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
Vendor Intel Intel
Build Integrated Discrete
Released 5-Jan-26 12-Oct-23
Case Laptop Desktop
Purpose Generic Gaming
Segment Entry-level Mid-range
Architecture Celestial Generation 12.7
GPU Codename Panther Lake DG2-512
Recommended CPU -Intel Core Ultra 9 386Hor above -Intel Core i5 12500or above
Graphics Processing Unit
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
Base Clock 2050 MHz
Boost Clock 2500 MHz 2400 MHz
Shading Units 3584
Texture Mapping Units (TMUs) 224
Render Output Units (ROPs) 112
Compute Units (Pipelines) 4
Tensor Cores 448
Ray-tracing Cores 28
L1 Cache 64KB per cluster
L2 Cache 4MB shared 16MB shared
Instructions Per Cycle 2 IPC 2 IPC
Raw Performance
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
Pixel Fill Rate 269 GPixel/s
Texture Fill Rate 538 GTexel/s
FLOPS (FP32) 17.2 TFLOPS
Physical
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
Interface PCIe 5.0 PCIe 4.0 x16
TGP 225 W
Manufacturing TSMC TSMC
Fabrication Process 3 nm 6 nm
Die Size 406 mm²
Transistor Count 21 billion
Transistor Density 51.72 MTr/mm²
Max. Temperature
Memory
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
Memory Type System Shared GDDR6
API
Specification Intel Xe3 Graphics ↗ Intel Arc A750 ↗
DirectX 12.1 12
Vulkan 1.4 1.3
OpenGL 4.6 4.6
OpenCL 3 3
CUDA
Ray Tracing Yes Yes
DLSS No No
DisplayPort 2.1 2
